Daktronics Provides Improved Visual Experience for Angel Stadium

The Los Angeles Angels were looking to improve the visual experience at their ballpark and turned to Daktronics to install more than 23,000 square feet of LED displays – the most of any MLB stadium.

The project includes the third largest video display in the majors as well as the first ever LED corner wraps to show graphics and content on the left and right edges of the main video display in a seamless fashion.

The team's "A" halo display also received a technology upgrade for high resolution as part of the installation. The project totals more than 17.1 million LEDS to inform and entertain fans at every event.

We believe this investment into Angel Stadium will dramatically enhance the overall experience for our loyal and dedicated fan base.

- John Carpino, Angels President

Engineering

Where a Vision Meets Reality

With more than 500 engineers on staff, our team continues to innovate and develop the next wave of LED technology for our customers, including the Angels, based on their specific applications. Our ability to effectively engineer displays like the new system at Angel Stadium, is an important reason Daktronics is the leading provider of large integrated display systems for professional sports and entertainment facilities.

Structural Engineering

Early collaboration in the design process to provide cost, time and infrastructure savings.

Halo Display

Custom Cabinet Design

Implemented customized-shaped cabinet designs for the marquee Halo and main video corner wraps.

Catwalk Structure

Re-Engineering Catwalk Structures

Right field and left field retrofit steel structures for continuous levels of catwalks.

Display Closeup

Elevated Nit Levels

To compete with the ever-present California sun, incorporated 11,000 nits of brightness for sustained daytime visibility.

Manufacturing

With more than 600,000 square feet of manufacturing space, Daktronics can handle the largest video display projects in the industry. With component level assembly in the USA, Daktronics can ensure the highest quality available on the market today.

Our manufacturing capabilities were recognized with a Frost & Sullivan Manufacturing Leadership Award for Operational Excellence in 2017.

Learn More About Manufacturing

Shipping
Shipping


Display Installation

Piecing it Together

Major stadium renovations have a lot of moving parts and multiple parties on site with differing schedules, timelines and milestones. A company with more than 800 combined years in project management has the experience to work through the construction schedule at Angel Stadium to bring an LED video solution to life on time and on budget. We know every moment matters.

Game Day

Achieving Your Final Goal

Featuring 15 individual LED displays and the 3rd largest video board in MLB, Angel Stadium incorporates more than 23,000 square feet of LED. With more LED square footage than any other MLB ballpark, Angel Stadium offers more real estate to provide the ultimate game-day experience.

Stadium Aerial View

Explore the Integrated System

Angel Stadium | Los Angeles Angels

Click the pins on the image to see more information about each display.

Right Field Main Display

Spacing: 13HD
Dimensions: 49' x 193' (14.99 m x 58.87 m)

Left Field Display

Spacing: 13HD
Dimensions: 49' x 112' (14.99 m x 34.01 m)

Home Plate Fascia

Spacing: 13HD
Dimensions: 3'7" x 60' (1.1 m x 18.28 m)

Lower Fascia (3rd)

Spacing: 13HD
Dimensions: 3'7" x 511'1" (1.10 m x 155.78 m)

Out of Town/Outfield Fence

Spacing: 13HD
Dimensions: 8'5" x 182'4" (2.56 m x 55.58 m)

Tunnel Fascia

Spacing: 13HD
Dimensions: 2'5" x 57'7" (.73 m x 17.55 m)

Tunnel Video Display

Spacing: 13HD
Dimensions: 16'10" x 57'7" (5.12 m x 17.55 m)

Vomitory Video Displays

Spacing: 13HD
Dimensions: 2'5" x 7'2" (.73 m x 2.19 m)
Quantity: 4

Helmet Entrance

Spacing: 10 mm
Dimensions: 3.6' x 36' (1.1 m x 10.97 m)

Big 'A' Marquee Billboard

Spacing: 20 mm
Dimensions: 35' x 42' (10.57 m x 12.6 m)

Big 'A' Halo

Spacing: 25 mm
Dimensions: 3'3" x 220' (1 m x 66.95 m)

Lower Fascia (1st)

Spacing: 13HD
Dimensions: 3'7" x 511'1" (1.10 m x 155.78 m)

Industry-leading Control System

Integrating every display at Angel Stadium, Daktronics powerful Show Control System runs the show. This industry-leading system provides a combination of display control software, world-class video processing, data integration and playback hardware that forms a user-friendly production solution. This control software includes the latest in content transitions, layering and shrink-to-fit features among other effects.

Learn More About Control

Control Room View of Angel Stadium

Support

Professional Services

Operations

After training with a Daktronics Control System Specialist, Angels operators were able to refine their layouts and designs and load and test all of their content. Our Control System Specialist was even on-site for the first few events.

Creative Services

By starting the digital content conversation early in the process, Daktronics Creative Services was able to completely understand the team's needs and work with them to develop their desired style of content.

Read the Case Study

Technical

Working with a Daktronics Applications Engineer has allowed the Angels to easily implement single-button control of game-day elements and data integration. Applications Engineers stays committed to the team as their needs change and evolve.

Sustaining Your Investment

Throughout the years and each installation process, Daktronics performance and reliable service staff has supported the Angels and their needs. After installation, our team remains committed to providing you with the best service in the industry. This includes experienced, reliable local service technicians available to support the installation 24/7. We provide one number to call if there are any issues that need to be resolved and will be there for your team throughout the lifetime of your display system.

Learn More About Our Service

​​​

Dedication

Our Commitment to the Angels


  1. 2004 - Angel Stadium

    Beginning in 2004, Daktronics provided an integrated video and scoring system for Angel Stadium.

    Angels Scoreboard
  2. 2010 - Tempe Diablo Stadium

    In 2010, Daktronics provided the scoring system at Tempe Diablo Stadium, the Angels' Spring Training facility.

    Training Field Display
  3. 2018 - Angel Stadium New Technology

    In 2018, the Angels again came back to Daktronics to engineer and install new video technology at Angel Stadium.

    New Outfield Displays

We're excited to continue our long-standing partnership with the Los Angeles Angels for this stadium-wide installation.

- Reece Kurtenbach, Daktronics President & CEO
