DAK Score

Mobile Scoring App

You can now control your Daktronics scoreboards with mobile devices and tablets (not included). Customizable names in the DAK Score app make it easy to identify which scoreboard you want to control.

Wireless Scoring At Your Fingertips

Using Bluetooth® wireless technology, the DAK Score mobile app sends commands to an indoor/outdoor interface box, which then directly controls one or more scoreboards via wired or wireless signal. An integrated 2.4 GHz radio transmitter in the interface box allows for a completely wireless scoring solution.

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Daktronics, Inc. is under license.

Dak Score App on Tablet and Phone

Device Requirements

  • Android 4.4 and higher
  • iOS 10 and higher

Operating Range

  • 50' (15 m) between mobile device and interface box
  • 1500' (457 m) between interface box and scoreboard

Try out the app in Demo mode to see how it works

Apple App Store Google Play App Store

MX-1 Interface Box

Operating Temperatures-22° to 122° Fahrenheit
(-30° to 50° Celsius)
Power2W, 0.4 A @ 5VDC (via 120 VAC adapter)
Weight1.5 lb (0.7 kg)
Dimensions4.7" H x 6.6" W x 2.8" D
(120 mm, 168 mm, 71 mm)
ConstructionGasketed Polycarbonate
MX-1 Interface Box

Control Options

Refer to the diagrams to see the available control options, and select one that best fits the needs of your facility.

Wired Connection

MX-1 Interface Box Diagram with Wired Connection

Radio Transmitter

MX-1 Interface Box Diagram with Wireless Connection

Note that placement of scoreboard antenna is for illustrative purposes only.

Compatible Scoreboard Models

We are continuing to expand cabability of this product to additional scoreboard models.

Baseball

BA-618
BA-624
BA-1518
BA-2005
BA-2010
BA-2014
BA-2017
BA-2019
BA-2022
BA-2023
BA-2026
BA-20281
BA-20291

BA-2030
BA-2031
BA-2033
BA-2034
BA-2035
BA-2125
BA-21271
BA-2515
BA-2518
BA-2618
BA-2715
BA-2718

Football

FB-824
FB-20182
FB-20192, 3
FB-20202, 3
FB-20212
FB-20222, 3
FB-20232, 3

FB-20242
FB-20252, 3
FB-20262
FB-20272, 3
FB-20282
FB-4005

Multisport

MS-915
MS-918
MS-2002
MS-2006
MS-2025
MS-3918

Soccer

SO-918
SO-2008
SO-2013
SO-20182
SO-20192
SO-20212
SO-20232, 3
SO-2918

1Speed of Pitch not currently supported
2Electronic captions not currently supported
35- and 6-digit timing not currently supported
