​Discontinued Products

Jump to:

All Sport Consoles
Timing consoles for scoreboards.
Billboards
Digital billboards designed for outdoor advertising.
DakTicker
LED ticker displays presenting scrolling data.
Data Display - Cinema
LED indoor and outdoor cinema solutions.
Data Display - Firehouses
Outdoor message and graphic displays for Firehouses/Firestations.
Data Display - Industrial
Outdoor message and graphic displays for industrial solutions.
DataMaster
Outdoor digits and controllers for gas, hotel, lottery, etc.
DataStreamer
Software enabling displays to present data feeds.
DataTime
Outdoor time and temperature digits.
DataTrac
Indoor text-only LED displays in red or tri-color.
Fuelight
Outdoor petroleum price digits.
Galaxy
LED matrix displays presenting text, graphics, and animations.
GalaxyPro
LED full-matrix video messaging displays.
GlowCube
Reflective displays; pixels rotate to form text and graphics.
InfoNet
Line-oriented LED displays presenting text.
ProPixel
Architectural lighting elements.
Scoreboards - Incandescent
Incandescent scoreboard systems.
Scoreboards - LED Outdoor
LED outdoor scoreboard systems.
Scoreboards - LED Indoor
LED indoor scoreboard systems.
Sports Consoles/Software
Consoles & software for sports displays.
Sportsound - Outdoor
Outdoor sound systems
Starburst
Incandescent full-matrix color displays presenting text, graphics, and animations.
SunSpot
All monochrome incandescent displays.
Vanguard
Dynamic Message Signs.
Venus
Message and animation display control systems.


All Sport Consoles

Consoles that control a scoreboard during an event.

All Sport Console Product Image

Daktronics control consoles feature liquid crystal display (LCD) screens to provide operators with visual feedback. Features of the All Sport® control consoles include a time-of-day display mode, 1/10 of a second timing and optional radio control to eliminate the need for signal wire.

Model Description Active Production Manuals
All Sport 100 Handheld controller for portable scoreboards 2003-2020 ED-13432
All Sport 2000 Controller for Scoreboard 1986-1995 ED-10102
All Sport 3000 Controller for Scoreboard 2000-2008 ED-12126
All Sport CG (SD) Outputs scoring information on top of Standard Definition (SD) video 2006-2016 ED-15365

Billboards

Digital billboards combines world-class image quality with several enhancements to save the customer time and money.

Billboard Product Image

Daktronics Digital Billboard series are outdoor matrix displays used to show dynamic advertisements and information. Full-color video displays with simple installation tailored for the Out of Home Advertising applications.

Model Description Active Production Manuals
DB-1000 Outdoor billboard in standard display sizes 2001-2008 DD1740664

DakTicker

LED ticker displays presenting scrolling data from external sources

DakTicker Product Photo

Outdoor digits for gas prices, hotel rates, lottery jackpots, events counters, and multipurpose displays. Displays produced with incandescent, GlowCube, and LED technologies. The controllers for digits are also known as DataMaster.

Model Description Active Production Manuals
KE-1010-7.6-RG Indoor, tri-color (R,G,A) LED, 7.6 mm spacing 2000-2007 ED-11634
ED-15353
KE-1010-34mm-RA Outdoor, red or amber LED, 34 mm spacing 2000-2007 ED-11634

Data Display - Cinema

LED indoor and outdoor cinema solutions

Data Display Cinema Product Photo

These are LED cinema solutions provided by Data Display in the years spanning 1990 – 2013. The displays provided eye catching and highly visible information to cinema goers in the outdoor area of the cinema, box office, lobby and auditorium.

Model Description Active Production Manuals
DLII220 Auditorium, 20 - 30 characters, Single line, Character Height 50mm or 100mm, Positioned at the entrance to each auditorium 1990-2013 N/A
DB055003 Box Office/Lobby, 50 - 70 characters, 5 - 8 line, 3cm high character 1990-2013 N/A
DLI1100 Box Office, Data Line, 100 characters, 3cm high characters 1990-2013 N/A
GB964820 Outdoor - Graphic Board, 96 pixels H x 48 pixels W, 20mm pitch 1990-2013 Banbridge Cinema
GB4162435 Outdoor - Graphic Board, 416 pixels H x 24 pixels W, 35mm pitch 1990-2013 Maya Cinemas
GB409631 Outdoor - Graphic Board, 40 pixels H x 96 pixels W, 31mm pitch 1990-2013 Regal Cinemas
GB329618 Outdoor - Graphic Board, 32 pixels H x 96 pixels W, 18.75mm pitch 1990-2013 Regal Cinemas
DLI-435 Indoor - Lobby Display, 4 Lines, 35 characters 1990-2013 Pacific Arc
DB22005 Auditorium, 2 lines, 20 characters 1990-2013 Pacific Arc

Data Display - Firehouses

Outdoor message and graphic displays for Firehouses/Firestations

Data Display Firehouse Product Photo

Displays used at firehouses and firestations for a variety of functions, including fund raising, recruitment, fire safety messages, and general fire house messages for public attention.

Model Description Active Production Manuals
GB 192x64 UBR Graphics Board, 192 pixels H x 64 pixels W, 5mm pitch, UBR 2000-2012 DDJ03185001
GB 48x128 UBA Graphics Board, 48 pixels H x 128 pixels W, 35mm pitch, UBA 2000-2012 DDJ05996001
GB 144x32 UBA Graphics Board, 32 pixels H x 144 pixels W, 18.75mm pitch, UBA 2000-2012 DDJ06822001
GB 64x120 UBR Graphics Board, 64 pixels H x 120 pixels W, 35mm pitch, UBR 2000-2012 DDJ07310001
GB 32x96 UBR Graphics Board, 32 pixels H x 96 pixels W, 15mm pitch, UBR 2000-2012 DDJ07850001
GB 24x64 UBR Graphics Board, 24 pixels H x 64 pixels W, 31mm pitch, UBR 2000-2012 DDJ08001001
GB 112x32 UBR Graphics Board, 32 pixels H x 112 pixels W, 18.75MM pitch, UBR  2000-2012 DDJ08123001
GB 96x16-UBR Graphics Board, 16 pixels H x 96 pixels W, 18.75mm pitch, UBR 2000-2012 DDJ08312001
GB 40x96-UBR Graphics Board, 40 pixels H x 96 pixels W, UBR 2000-2012 DDJ09288001
GB 40x128-UBR Graphics Board, 40 pixels H x 128 pixels W, UBR 2000-2012 DDJ09783001
GB 32x304-UBR Graphics Board, 32 pixels H x 304 pixels W, UBR 2000-2012 DDJ09839001
GB 112x24-UBR Graphics Board, 24 pixels H x 112 pixels W, UBR 2000-2012 DDJ10098001
GB 40x96-UBA Graphics Board, 40 pixels H x 96 pixels W, UBA 2000-2012 DDJ10146001
GB 128x40-UBR Graphics Board, 40 pixels H x 128 pixels W, UBR 2000-2012 DDJ10682001
GB 112x32-UBA Graphics Board, 32 pixels H x 112 pixels W, UBA 2000-2012 DDJ10721001
GB 176x96-UBR Graphics Board, 176 pixels H x 96 pixels W, UBR 2000-2012 DDJ11752001
GB 96x32-UBR Graphics Board, 32 pixels H x 96 pixels W, UBR 2000-2012 DDJ12104001
GB 112x40-UBR Graphics Board, 40 pixels H x 112 pixels W, UBR 2000-2012 DDJ12797001
GB 128x40-UBR Graphics Board, 40 pixels H x 128 pixels W, UBR 2000-2012 DDJ13713001
GB 96x256-UBA Graphics Board, 96 pixels H x 256 pixels W, UBA 2000-2012 DDJ13777001
GB 96x256-UBR Graphics Board, 96 pixels H x 256 pixels W, UBR 2000-2012 DDJ14487001
GB 96x40-UBR Graphics Board, 40 pixels H x 96 pixels W, UBR 2000-2012 DDJ15862001

Data Display - Industrial

Outdoor message and graphic displays for Industrial solutions

DataDisplay Industrial Product Photo

These are LED solutions provided by Data Display in the years spanning 1990 - 2013. Products include electronic health & safety displays and production line displays for manufacturing floors.

Model Description Active Production Manuals
DDUB2506 Production Board, 5mm pitch, High Bright Red 1990-2013 DD0013N
J01619-1620 Production Board, 5mm pitch, Standard Bright Red 1990-2013 DDJ01619-1620
DL405R Production Board, 5mm pitch, Standard Bright Red 1990-2013 DDJ01905001
J02706001 Production Board, Standard-Bright Green and Multicolour 1990-2013 DDJ02706001
DB-PRODN BOARD-IN 5CM TAKT Time Counter Production Board, 4 Line, 5cm characters, Standard Bright Red 1990-2013 DDJ04568001
DB-Prod070505-HBR Safety Display Board, 7 Line 5 Characters per line, 50mm character height, Standard Bright Red 1990-2013 DDJ04770001
DDJ04902001
DB-PRODNBOARD-SPECIAL-HBR Production Display Board, 5 Data Board, 1 Data Line, 100mm character height, Standard Bright Red 1990-2013 DDJ06001001
DDUB2506 Production Board, LED Diameter 5mm, High Bright Red 1990-2013 DDJ06334001
DB03 10 08 / Dli 330 Production Display Board, 3 Data Board, 1 Data Line, 3 Inch character height, Super Bright Red 1990-2013 DDJ06553001
DB-069510-UBR Production Display Board, 6 Line, 10 Character per line databoard, 15 characters per line dataline, 100mm character height, Ultra Bright Red 1990-2013 DDJ07263001
J07334001 Production Display Board, 6 Line, 10 and 20 characters per line, 50mm character height, Standard Bright Red 1990-2013 DDJ07334001
J09975001 Production Display Board, 4 lines per board, type 1, 2 lines per board type 2, 50mm character height 1990-2013 DDJ09975001
PDB-030605-SMT/RED/MULTI Production Display Board, 3 lines, 6 characters per line, 2 inch character height, TARGET in red, ACTUAL and EFFICIENCY in red, amber or green depending on the performance level. 1990-2013 DDJ10042001
J11532001 Production Display Board, 4 lines on data board, Single line data line, 15 characters per line, 80mm character height, Ultra Bright Red and Amber 1990-2013 DDJ11532001
DB-043010-SMTR/G/A TAKT Time Counter Production Board, 4 lines per board, characters per line: 5 on top 3 lines, 15 on scrolling data line, 10cm character height 1990-2013 DDJ11893001
J13118001 Production Display Board, 3 Lines per board, 10 characters per line, 50mm character height, Red and Amber 1990-2013 DDJ13118001
DL405NSMCG & DL405NSMCRG Production Display, 7 Line Target/Actual display with date, week number and clock fields, 20 character scrolling dataline at the bottom, 4 inch character height, Surface Mount Red, Green and Amber 1990-2013 DDJ14154001
DB-051005 Production Board, 5 Line, 10 Characters per line, 50mm high characters, Ultra Bright Amber and Red 1990-2013 DDJ14444001
DDJ15540001 Production Display, Time/Temp top corner, 30mm high characters, Ultra Bright Red 1990-2013 DDJ15540001
DD5244 Production Board, Standard Bright Red 1990-2013 DD5244
DD10858 Graphics Board, EPROM - NORTEL OBJ 1990-2013 DD10858
DD11743 Production Board, EPROM - 50DUM96DSY -90DUM96DSY 1990-2013 DD11743
DD12305 Target/Actual Production Board, 6 Lines per board, 5 characters per line 100mm character height, Standard Bring Red 1990-2013 DD12305
DB103003MK Production Board, 11 Lines per board, 30 characters per line, 3cm character size, Multicolor 1990-2013 DD12317
DD12460 Production Board, 5 character 2" high Databoards, 5 character 2" high scrolling Dataline, and a 5 character 2" high clock, High Bright Red 1990-2013 DD12460
J02008001 Production Board, DL405R, 18 off, Standard Bright Red 1990-2013 DDJ02008001
DBTARGET/ACTUAL Production Board, 4 lines per board, 10cm character height, Standard Bright Red 1990-2013 DDJ02071001
J02163001 Production Board, 4 lines per board, 10cm character height, Standard Bright Red 1990-2013 DDJ02163001
J02235001 Production Board, DL210M/C HB, 18 off, High Bright Multicolor 1990-2013 DDJ02235001
DDJ02806001 Production Board, DL210 SBR, Standard Bright Red 1990-2013 DDJ02806001

DataMaster

Outdoor digits and controllers for gas, hotel, lottery, etc.

DataMaster Product Photo

Outdoor digits for gas prices, hotel rates, lottery jackpots, events counters, and multipurpose displays. Displays produced with incandescent, GlowCube, and LED technologies. The controllers for digits are also known as DataMaster.

Model Description Active Production Manuals
DF-1020 Outdoor gas price digit, (R,G,A) LEDs, 10"-60" digit 2001-2006 ED-13750
DF-1030 Outdoor 2 digit rate, red or amber LEDs, 13"-48" digit 2001-2006 ED-13751
DF-1040 Outdoor 4 digit rate, red or amber LEDs, 13"-48" digit 2001-2006 ED-13751
DF-1050/1051/1052/1053 Outdoor digit parking 2001-2006 ED-14139
DF-1060 3-digit lottery display, 24"-60" character heights, red or amber LEDs 2001-2006 ED-14305
DF-1070 Custom-made multi-digit event counter display, customer-specified digit size, color and cabinet 2001-2006 N/A
DF-12xx Multi-product gas price display or matrix and digit combo display, 10"-24" character heights, (R,G,A) LEDs, with or without ID panel 2003-2005 ED-15043
ED-15089
ED-15177
DF-2000 Gas price display, 10"-96" character height, (R,G,A) LEDs, drop-in or single-face cabinet without ID panel 2006-2007 ED-16167
DF-2100 Gas price display, 10"-60" character height, (R,G,A) LEDs, single-face or double-face cabinet with ID panel 2006-2008 ED-16375
ED-16637
ED-16374
DF-4000 Gas price displays intended for international market, 10"-24", (R,G,A) LEDs, drop-in cabinet 2006-2008 ED-16084
MF-1000/1001/1002/1003/1004 Outdoor Status/Lane Indicator Display 2001-2008 ED-16705

DataStreamer

Software enabling displays to present data feeds

DataStreamer Logo

Software that controls DataTrac and DakTicker displays. Streams data to the displays from an external source through financial, news, weather, and sports feeds.

Model Description Active Production Manuals
N/A N/A 2000-2007 ED-13649

DataTime

Outdoor LED time and temperature displays.

DataTime Product Photo

Outdoor digits to display the current time and temperature with LED technology, in red or amber color.

Model Description Active Production Manuals
DF-1010
DF-1011
Outdoor digit display, red or yellow LEDs, 10”-24” digits 2001-2013 ED-13752

DataTrac

Indoor character-based, text-only LED displays in red or tri-color

DataTrac Product Photo

Indoor character-based, text-only LED displays in red or tri-color. Variety of lines high with several character heights. Produced in smaller and larger panelized models.

Model Description Active Production Manuals
S-100/S-200 Indoor alpha-numeric, red or tri-color (R,G,A), 0.7"-2.1" character heights, polycarbonate face 1996-2008 ED-10191
CE-1010 Indoor alpha-numeric, red or tri-color (R,G,A), 1.2"-4.2" character heights, sectional with mesh 1996-2008 ED-11477

Fuelight

Outdoor petroleum price digits

Fuelight Product Photo

Outdoor digits for gas prices produced with LED technology, in red, amber, or green color. These digits are controlled by Fuelink control kits.

Model Description Active Production Manuals
FL-2000 Outdoor 3-digit with 9/10 digit, drop-in cabinet, red, amber or green LEDs, 7”-27” digits 2008-2012 DD1398860
FL-2100 Outdoor 3-digit with 9/10 digit, single or double-face cabinet with ID panel, red, amber or green LEDs, 12”-24” digits 2008-2012 DD1398897
FL-2109 Outdoor 3-digit with 9/10 digit, single-face configuration, drop-in cabinet, product panel ID, optional cash/credit ID, red, amber or green LEDs, 36”-60” digits 2007-2014 DD1398926
FL-4000 Outdoor 4-digit for international markets, drop-in cabinet, red, amber or green LEDs, 7”-24” digits 2008-2012 DD1398943

Galaxy

LED matrix displays presenting text, graphics, and animation.

Galaxy Product Photo

Indoor or outdoor full-matrix message displays for dynamic advertising of text messages, graphic images, or animations. Produced in full color, monochrome red or amber. Some contain on-board memory for storing messages.

Model Description Active Production Manuals
AE-3010-7.6-R,G,A Outdoor matrix, tri-color (red, green and amber) LEDs, 7.6 mm spacing 1996-2012 ED-11169
AF-3010-34 Outdoor matrix, red LED, 34 mm spacing, polycarbonate face 1998-2004 ED-10972
AF-3020-7.6-R,A Outdoor matrix, red or amber LEDs, 20 mm spacing 2002-2007 ED-13518
AF-3050-20-R,A Outdoor matrix, red or amber LEDs, 20 mm spacing 2002-2007 ED-13462
AF-3060-34-R,A Outdoor matrix, red or amber LEDs, 34 mm spacing 2000-2002 ED-12061
AF-3060-34-R,G Outdoor matrix, tri-color (R,G,A) LEDs, 34 mm spacing 2000-2002 ED-12061
AF-3065-34-R,G Outdoor matrix, tri-color (R,G,A) LEDs, 34 mm spacing 2001-2002 ED-12835
AF-3080-68-R,A Outdoor matrix, red or amber LEDs, 68mm spacing 2003 ED-13620
AF-3090-89-R,A Outdoor matrix, red or amber LEDs, 89mm spacing 2002 ED-13288
AF-3112-34-R,A Outdoor matrix, red or amber LEDs, 34mm spacing, polycarbonate face 2002 ED-14212
AF-3150-20-R,A Outdoor matrix, red or amber LEDs, 20mm spacing 2003-2004 ED-13745
AF-3155-20-RGB Outdoor matrix, RGB LEDs, 20mm spacing 2003-2004 ED-13908
AF-3160-34-R,A Outdoor matrix, red or amber LEDs, 34mm spacing 2003-2004 ED-13767
AF-3165-34-RGB Outdoor matrix, red or amber LEDs, 34mm spacing 2002-2004 ED-13797
ED-13607
AF-3190-89-R,A Outdoor matrix, red or amber LEDs, 89mm spacing 2003-2005 ED-13744
AF-3197-89-RGB Outdoor matrix, RGB LEDs, 89mm spacing 2003-2005 ED-14037
AF-3200-34-RGB Outdoor matrix, red or amber or RGB LEDs, 34mm spacing, polycarbonate face 2007-2010 ED-16958
AF-3200-89-RGB Outdoor matrix, RGB LEDs, 89mm spacing 2004-2007 ED-15400
AF-3220 Series 34mm Outdoor RGB or Monochrome 34mm spacing 2009-2015 DD1758104
AF-3220-12-RGB/20-R Outdoor matrix, red and RGB LEDs, 34mm and 12mm spacing 2005-2006 ED-15507
AF-3400-12-RGB Outdoor matrix, RGB LEDs, 12mm spacing 2006-2007 ED-17998
AF-3400-20-R,A,RGB Outdoor matrix, red or amber or RGB LEDs, 20mm spacing 2004-2008 ED-16421
AF-3400-34-R,A,RGB Outdoor matrix, red or amber or RGB LEDs, 34mm spacing 2004-2008 ED-16680
AF-3400-64-R,A Outdoor matrix, red or amber LEDs, 64mm spacing 2005-2007 ED-16004
AF-3400-46-R,A,RGB Outdoor matrix, red or amber or RGB LEDs, 46mm spacing 2005-2009 ED-15477
AF-3400-89-R,A,RGB Outdoor matrix, red or amber or RGB LEDs, 89mm spacing 2005-2008 ED-15400
AF-3400-133,171,216,260 Outdoor matrix, red or amber LEDs, 133/171/216/260mm spacing 2005-2008 ED-15630
AF-3500-20-RGB Outdoor matrix, RGB LEDs, 20mm spacing 2008-2012 DD1377306
AF-3500-34-RGB Outdoor matrix, RGB LEDs, 34mm spacing 2008-2012 DD1377306
AF-3500-46-R,A,RGB Outdoor matrix, red or amber or RGB LEDs, 46mm spacing 2009-2014 DD1674581
AF-6120 Series Outdoor Monochrome 8mm spacing 2007-2010 Custom Manual
C-200 Series Indoor, tri-color (R,G,A) LED, 8mm spacing 1996-2004 Custom Manual
X-200 Series Indoor, tri-color (R,G,A) LED, 8mm spacing 1996-2012 Custom Manual
X-1000 Series Outdoor Monochrome 8mm spacing 1996-2007 Custom Manual

GalaxyPro

LED full-matrix video messaging displays

GalaxyPro Product Photo

Outdoor full-matrix marquee displays presenting video, text, graphics and animations in great detail. Full-color video displays with simple installation.

Model Description Active Production Manuals
AF-3700-20 RGB Outdoor matrix, RGB LEDs, 20mm spacing 2006-2008 ED-16281
AF-3700-34 RGB Outdoor matrix, RGB LEDs, 34mm spacing 2007-2010 ED-17286
GPR-12EV-RGB Outdoor matrix, RGB LEDs, 12mm spacing 2008-2011 DD1359021
DD1359049
GPR-16-RGB Outdoor matrix, RGB LEDs, 16mm spacing 2009-2011 DD1359021
DD1359049
GPR-20-RGB Outdoor matrix, RGB LEDs, 20mm spacing 2008-2011 DD1359021
DD1359049
GPR-23-RGB Outdoor matrix, RGB LEDs, 23mm spacing 2008-2011 DD1359021
DD1359049
GP3-16-RGB Outdoor matrix, RGB LEDs, 16mm spacing 2011-2012 DD2066138
DD1931807
GP3-20-RGB Outdoor matrix, RGB LEDs, 20mm spacing 2010-2012 DD2066138
DD1931807
GP3-26-RGB Outdoor matrix, RGB LEDs, 20mm spacing 2010-2012 DD2066138
DD1931807
GP4-16-RGB Outdoor matrix, RGB LEDs, 16mm spacing  2012-2016 DD2405872
DD2405882
DD1931894
GP4-20-RGB Outdoor matrix, RGB LEDs, 20mm spacing  2012-2016 DD2405872
DD2405882
DD1931894
GP4-26-RGB Outdoor matrix, RGB LEDs, 26mm spacing  2012-2016 DD2405872
DD2405882
DD1931894

GlowCube

Reflective displays, digit, or pixels that rotate to form text and graphics

GlowCube Product Photo

Reflective displays that use three-dimensional pixels, containing a black and fluorescent yellow side. Pixels rotate to create text and graphics or digits. Wide variety of matrix or digit sizes.

Model Description Active Production Manuals
Matrix, Line, and Digit N/A 1996-1999 ED-6146
GP-99 Portable GlowCube Scoreboard 1994-2001 ED-8035
ED-10646
MS-2001 Portable GlowCube Scoreboard 1999-2001 ED-11443

InfoNet

Line-oriented LED displays presenting text.

InfoNet Product Photo

Small, line-oriented displays, one-line format in tri-color or monochrome. Used for displaying text messages.

Model Description Active Production Manuals
G-1000-34-R Outdoor line, red LEDs, 34mm spacing 1996-2000 ED-8157
G-100-7.6-R Indoor line, red LEDs, 7.6mm spacing 1996-2002 ED-10190
ED-9848
G-200-x (Multi Line) Indoor, single-line display, (R,G,A) colors, 2.1" character height 1997-2001 ED-9848
G-200-1 (Single Line) Indoor, multi-line display, (R,G,A) colors, 2.1" character height 1997-2010 ED-10190
Labelle GL100 Indoor line, red LEDs, 7.6mm spacing 1996-1999 ED-8722
ED-8969
Silent Radio Indoor line, red LEDs, 7.6mm spacing 1996-1999 ED-8722
ED-8969
Cybernetics Indoor line, red LEDs, 7.6mm spacing 1996-1997 ED-8722
ED-8969
NorthStar Indoor line, red LEDs, 7.6mm spacing 1996-1999 ED-8722
ED-8969

ProPixel

Architectural lighting elements

ProPixel Product Photo

Daktronics ProPixel freeform products use mountable LED elements to transform ordinary structures into stunning visual landmarks. A flexible mounting platform allows designers to transform any structure into a full-motion video display guaranteed to leave a lasting impression.

Model Description Active Production Manuals
PSX-5102 Freeform lighting element that can be used to create a semi-transparent matrix or architectural lighting. 2009-2013 N/A

Scoreboards - Incandescent

Incandescent scoreboard systems.

Incandescent Scoreboard Product Photo

Incandescent scoreboards for multiple sports in a variety of digit sizes.

To view current manuals visit our scoreboard manuals page for manuals on current scoreboard and timing systems.

Model Description Active Production Manuals
BB-1013B
BB-1013S
BB-1713B
BB-1713S
BB-1713B-A
BB-1713S-A
Indoor incandescent basketball scoreboards N/A ED-3367
H-813S
H-2013S
H-2813S
H-813B
H-2013B
H-2813B
Indoor incandescent hockey scoreboards N/A ED-3364
BA-1518
BA-1524
BA-3718
BA-3724
FB-1424
FB-1430
FB-1524
FB-1530
FB-1624
FB-1630
FB-1630L
FB-1730
FB-1830
FB-1830L
FB-2001
FB-2002
FB-2003
FB-2004
MS-2009
MS-2118
SO-1424
SO-1624
SO-1830
SO-1930
SO-2030
Outdoor incandescent multi-section scoreboards N/A ED-11973
  Outdoor incandescent single-section scoreboards N/A ED-11974
CH-24-DS Chrondek drag race timing display N/A ED-4474
CH-36-DS Chrondek drag race timing display N/A ED-4760
CH-1421-H
CH-1521-H
Chrondek drag race timing display N/A ED-4765
CH-1424 - WB Chrondek drag race timing display N/A ED-5336
CH-424 Chrondek auto racing display N/A ED-5888
CH-1024H Chrondek auto racing display N/A ED-5891
CH-2024V Chrondek auto racing display N/A ED-5900
CH-1624V Chrondek auto racing display N/A ED-5942
CH-836H Chrondek auto racing display N/A ED-5965
CH-1318V Chrondek auto racing display N/A ED-6041
CH-1421V Chrondek auto racing display N/A ED-6041
CH-1018H Chrondek auto racing display N/A ED-6581
CH-936H Chrondek auto racing display N/A ED-6515
CH-1036H Chrondek auto racing display N/A ED-6616
CH-1618H Chrondek auto racing display N/A ED-7010
CH-1018V Chrondek auto racing display N/A ED-7029
CH-1124V Chrondek auto racing display N/A ED-7048
CH-1436H Chrondek auto racing display N/A ED-7931
CH-1036V
CH-1436V
Chrondek auto racing display N/A ED-8660
CH-1618V Chrondek auto racing display N/A ED-9542

Scoreboards - LED Outdoor

Outdoor LED Scoreboards

Outdoor Scoreboard Product Photo

LED scoreboards for multiple sports in a variety of digit sizes.

To view current manuals visit our scoreboard manuals page for manuals on current scoreboard and timing systems.

Model Description Active Production Manuals
Single-Section LED Scoreboards 1999-2002
(Gen II)
ED-12561
BA-515
BA-518
BA-618
BA-624
BA-718
BA-1018
BA-2003
BA-2004
BA-2005
BA-2010
CT-2001
CT-2002
FB-824
FB-2005
MS-915
MS-918
MS-2002
MS-2004
MS-2006
MS-2012
SO-918
SO-2008
SO-2009
SO-2010
TI-218
TI-418
TI-2003
TI-2019
Single Section LED Scoreboards 1999-2002
(Gen II)
ED-13038
BA-1518
BA-1524
BA-2007
BA-3718
BA-3724
FB-1424
FB-1430
FB-1524
FB-1530
FB-1624
FB-1630
FB-1630L
FB-1730
FB-1830
FB-1830L
FB-2001
FB-2002
FB-2003
MS-2009
MS-2118
SO-1424
SO-1624
SO-1830
SO-1830L
SO-1930
Multi-Section LED Scoreboards 1999-2002
(Gen II)
ED-12562
BA-1518
BA-1524
BA-2007
BA-3718
BA-3724
CR-2001
FB-1424
FB-1430
FB-1524
FB-1530
FB-1624
FB-1630
FB-1630L
FB-1730
FB-1830
FB-1830L
FB-2001
FB-2002
FB-2003
FB-2004
MS-2009
MS-2118
MS-2918
SO-1424
SO-1624
SO-1830
SO-1830L
SO-1930
Multi-Section LED Scoreboards 1999-2002
(Gen II)
ED-13109
BA-2001
BA-2002
BA-2008
LED Baseball Scoreboards 1999-2002
(Gen II)
ED-13131
MS-2014
MS-2015
MS-2016
MS-2018
LED Modular Scoreboards 1999-2002
(Gen II )
ED-13084
RO-2010
RO-2011
TI-2010
TI-2012
TI-2015
Timing Displays 1999-2002
(Gen II)
ED-13313
TN-2007
TN-2008
TN-2009
TN-2016
LED Tennis Scoreboards (5" & 10" Digit) 1999-2006
(Gen II-III)
ED-12420
BA-515
BA-518
BA-618
BA-624
BA-718
BA-1018
BA-2003
BA-2004
BA-2005
BA-2010
BA-2011
BA-2014
BA-2016
BA-2017
BA-2019
CR-2002
CR-2003
CT-2001
CT-2002
FB-824
FB-2005
FB-2410
MS-915
MS-918
MS-2002
MS-2003
MS-2004
MS-2006
MS-2011
MS-2012
RO-2010
RO-2011
SO-918
SO-2008
SO-2009
SO-2010
SO-2013
TI-215
TI-218
TI-418
TI-2003
TI-2010
TI-2012
TI-2015
TI-2019
TI-2024
Single Section LED Scoreboards 2002-2006
(Gen III)
ED-13770
BA-1518
BA-1524
BA-2006
BA-2007
BA-2012
BA-2013
BA-2020
BA-3718
BA-3724
FB-1424
FB-1430
FB-1524
FB-1530
FB-1624
FB-1630
FB-1630L
FB-1730
FB-1830
FB-1830L
FB-2001
FB-2002
FB-2003
FB-2004
FB-2007
MS-2009
MS-2020
MS-2118
MS-2918
SO-1424
SO-1624
SO-1830
SO-1830L
SO-1930
SO-2011
SO-2014
SO-2030
Multi-Section LED Scoreboards 2002-2006
(Gen III)
ED-13771
BA-2001
BA-2002
BA-2008
BA-2009
BA-2018
LED Baseball Scoreboards 2002-2006
(Gen III)
ED-13788
FB-2006
MS-2014
MS-2015
MS-2016
MS-2017
MS-2018
LED Stackable (Modular) Scoreboards 2002-2006
(Gen III)
ED-14091
TN-2010
TN-2011
TN-2018
TN-2029
TN-2032
TN-2037
TN-2042
LED Tennis Scoreboards 2002-2006
(Gen III)
ED-13890
RO-2002
RO-2008
RO-2009
LED Rodeo Scoreboards 2002-2006
(Gen III-IV)
ED-13357
BA-515
BA-518
BA-618
BA-624
BA-718
BA-1018
BA-2003
BA-2004
BA-2005
BA-2010
BA-2011
BA-2014
BA-2016
BA-2017
BA-2019
BA-2022
BA-2023
BA-2024
CR-2002
CR-2003
CT-2001
FB-824
FB-2005
FB-2410
MS-915
MS-918
MS-2002
MS-2003
MS-2004
MS-2006
MS-2011
MS-2012
RO-2010
RO-2011
SO-918
SO-2008
SO-2013
TI-215
TI-218
TI-418
TI-2003
TI-2010
TI-2012
TI-2015
TI-2019
TI-2024
Single-Section LED Scoreboards 2006-2008
(Gen IV)
ED-16959
BA-515
BA-518
BA-618
BA-624
BA-718
BA-1018
BA-2003
BA-2004
BA-2005
BA-2010
BA-2014
BA-2017
BA-2019
BA-2022
BA-2023
CR-2002
CR-2003
FB-824
FB-2005
FB-2410
MS-915
MS-918
MS-2002
MS-2003
MS-2004
MS-2006
MS-2011
MS-2012
RO-2010
RO-2011
SO-918
SO-2008
SO-2013
TI-215
TI-218
TI-2003
TI-2010
TI-2012
TI-2015
TI-2019
TI-2024
Single Section LED Scoreboards 2008-2009
(Gen IV)
ED-18754
BA-618
BA-624
BA-2003
BA-2005
BA-2010
BA-2014
BA-2017
BA-2019
BA-2022
BA-2023
BA-2024
BA-2515
BA-2518
BA-2618
BA-2715
BA-2718
CR-2002
CR-2003
FB-824
FB-4005
MS-915
MS-918
MS-2002
MS-2004
MS-2006
MS-2012
MS-2025
MS-3918
RO-2010
RO-2011
SO-918
SO-2008
SO-2013
SO-2918
TI-218
TI-2003
TI-2010
TI-2012
TI-2015
TI-2019
TI-2024
TI-2032
Single-Section LED Scoreboards 2009-2013
(Gen IV)
Installation:
DD1755790

Service:
DD1552971
DD2124597
BA-515
BA-518
BA-718
BA-1018
BA-2004
BA-2011
BA-2016
CT-2001
FB-2005
FB-2410
MS-2003
MS-2011
SO-2031
TI-215
TI-418
Single-Section LED Scoreboards 2009-2013
(Gen IV)
Installation:
N/A

Service:
DD1552971
BA-618
BA-624
BA-2005
BA-2010
BA-2014
BA-2017
BA-2019
BA-2022
BA-2030
CR-2003
FB-824
FB-2030
MS-918
MS-2002
MS-2004
MS-2006
MS-2012
MS-2024
SO-918
SO-2008
SO-2013
TI-2024
Single-Section LED Scoreboards (P1647) 2011-2015 (Gen IV) Installation:
DD2118213

Service:
DD2124597
BA-1518
BA-1524
BA-2006
BA-2007
BA-2012
BA-2013
BA-2020
BA-3718
BA-3724
FB-1424
FB-1430
FB-1524
FB-1530
FB-1624
FB-1630
FB-1630L
FB-1730
FB-1830
FB-1830L
FB-2001
FB-2002
FB-2003
FB-2004
FB-2007
MS-2009
MS-2020
MS-2118
MS-2918
SO-1424
SO-1624
SO-1830
SO-1830L
SO-1930
SO-2011
SO-2014
SO-2030
Multi-Section LED Scoreboards 2006-2009
(Gen IV)
ED-16960
BA-1518
BA-1524
BA-2013
BA-3718
BA-3724
FB-2018
FB-2019
FB-2020
FB-2021
FB-2022
FB-2023
FB-2024
FB-2025
FB-2026
FB-2027
FB-3010
MS-2009
MS-2918
SO-2011
SO-2018
SO-2019
SO-2021
SO-2022
SO-2023
Multi-Selection LED Scoreboards 2009-2011
(Gen IV)
ED-17610
BA-1518
BA-2025
BA-2026
BA-2027
BA-2028
BA-2029
FB-2018
FB-2019
FB-2020
FB-2021
FB-2022
FB-2023
FB-2024
FB-2025
FB-2026
FB-2027
FB-3010
MS-2009
MS-2918
SO-2011
SO-2018
SO-2019
SO-2021
SO-2023
SO-2043
Multi-Selection LED Scoreboards (P1647) 2011-2015
(Gen IV)
Installation:
DD1969938

Service:
DD2124597
BA-624
BA-1018
BA-2004
BA-2010
BA-2515
BA-2618
BA-2715
BA-2718
FB-824
FB-4005
MS-915
MS-2004
MS-3918
SO-2008
SO-2013
SO-2918
TI-2015
Single-Section LED DistaView Scoreboards 2006-2009
(Gen IV)
ED-16962
  Multi-Section LED DistaView Scoreboards 2006-2009
(Gen IV)
ED-16963
BA-2001
BA-2002
BA-2008
BA-2009
BA-2018
LED Baseball Scoreboards 2006-2010
(Gen IV)
ED-16961
FB-2350 Series LED Football Scoreboards 2006-2010
(Gen IV)
ED-14129
CR-2004 Multi-Section LED Cricket Scoreboard 2006-2011
(Gen IV)
ED-16242
  LED Tennis Scoreboards 2006-2011
(Gen IV)
ED-16442
  Single-Court LED Tennis Scoreboards 2011-2012
(Gen IV)
DD2172229
  LED Tennis Scoreboards 2011-2015
(Gen IV)
Installation:
DD2157207

Service:
DD2124597
FB-2500 Series
FB-2600 Series
Modular LED Football Scoreboards 2012-2013
(Gen IV)
Installation:
DD2363266

Service:
DD2124597
All Outdoor Scoreboards with Horns Trumpet Horn Installation 1995-2015
(Gen I-IV)
ED-10006
TI-2025
TI-2026
Portable segment timing displays 2006-2020 ED-16738

Scoreboards - LED Indoor

Indoor LED Scoreboards

Indoor Scoreboard Product Photo

LED scoreboards for multiple sports in a variety of digit sizes.

To view current manuals visit our scoreboard manuals page for manuals on current scoreboard and timing systems.

Model Description Active Production Manuals
All Sport
Junior
All Sport Junior Portable Scoreboard 1993-1998 ED-6965
BB-114-CL All Sport Jr. Portable Scoreboard 1993-1998 ED-7203
BB-114
BB-314
Portable Basketball Scoreboards 1999-2014 ED-13315
BB-1013L
BB-1013LB
BB-1713L
BB-1713LB
BB-1813L
BB-1813LB
LED Basketball Scoreboards (-L & -LB Models) 1995-1999
(Gen I)
ED-8819
  LED Basketball Scoreboards (-9 Models) 1995-1999
(Gen I)
ED-10718
  LED Aquatics Displays (10") 1995-1999
(Gen I)
ED-9501
  LED Hockey Scoreboards (-9 Models) 1995-1999
(Gen I)
ED-10915
  LED Basketball Scoreboards 1999-2015
(Gen II)
ED-11985
  LED Basketball Scoreboards 1999-2015
(Gen II)
ED-13110
  Four-Sided LED Basketball Scoreboards 1999-2015
(Gen II)
ED-13248
  LED Hockey Scoreboards 1999-2015
(Gen II)
ED-12998
H-2024
H-2026
H-2031
LED Four-Sided Hockey Scoreboards 1999-2015
(Gen II)
ED-11992
H-2105
H-2107
H-2109
H-2112
LED Four-Sided Hockey Scoreboards 1999-2015
(Gen II)
ED-13442
  LED Tennis Scoreboards 1999-2015
(Gen II)
ED-16309
TN-2560
TN-2561
TN-2562
TN-2563
Multi-Court LED Tennis Scoreboards 1999-2015
(Gen II)
DD2407654
VB-2101 LED Volleyball Scoreboards 1999-2015
(Gen II)
ED-13515
GM-2101
GM-2102
GM-2103
LED Gymnastics Scoreboards 1999-2000
(Gen II)
ED-13243
  LED Aquatics/Track Scoreboards 1999-2015
(Gen II)
ED-12156
WP-2101
WP2102
LED Water Polo Scoreboards 1999-2014
(Gen II)
ED-13769
CU-2001 LED Curling Scoreboards 1999-2015
(Gen II)
DD1862870
SQ-2001 LED Squash Scoreboards 1999-2015
(Gen II)
ED-12365
  ColorSmart Basketball Scoreboards 2007-2013 ED-16711
  Four-Sided ColorSmart Basketball Scoreboards 2007-2013 ED-18580
TI-2011
TI-2013
4-Inch LED Bar-Digit Locker Room Clocks 2002-2007 ED-12315

Sports Consoles/Software

Consoles & software for sports displays

CARS Logo

Model Description Active Production Manuals
Cars Chrondek automated racetrack software N/A ED-4790
C33 Drag race timer version 3 N/A ED-4727
C44 Drag race timer version 4.01 and higher N/A ED-7175
TSI Interface Works with Chrondek scoreboards N/A ED-8859
Finish Light Systems Finish Light Systems N/A ED-5469

Sportsound

Sportsound-Outdoor

Sportsound Product Photo

Outdoor sound systems.

Model Description Active Production Manuals
Sportsound 1000 Outdoor sound system 2003-2008 (Gen I)
2007-2009 (Gen II)
2008-2009 (Gen III)
ED-15605
ED-18519
DD1288390

Starburst

Incandescent full-matrix color displays presenting text, graphics, and animation.

Starburst Product Photo

Incandescent, full-matrix displays presenting text, graphics, and animations in full-color using red, green, blue, and white lamps or lenses.

Model Description Active Production Manuals
AB-1010 Outdoor matrix, incandescent bare lamp 1996-2001 ED-12161
AB-1500-1.5,2.5 Outdoor matrix, incandescent wedge-base lamp with lens, 1.5" and 2.5" spacing 1998-1999 ED-11119
AB-1600-1.5,2.5 Outdoor matrix, incandescent wedge-base lamp with lens, 1.5" and 2.5" spacing. 1998-2003 ED-11946
ED-10941
ED-11943
ED-11944

SunSpot

All monochrome incandescent displays, including reflector/lamp/lens design and bare lamp.

SunSpot Product Photo

Monochrome lamp displays that use reflector lamp and horizontal louvers. Used to display text messages, graphics, and animations in a variety of character sizes.

Model Description Active Production Manuals
Series 100 Outdoor matrix, incandescent bare lamp 1996-1998 ED-5216
Series 200 Outdoor matrix, incandescent bare lamp 1996-1998 ED-5216
AB-1010 Outdoor matrix, incandescent bare lamp 1996-2001 ED-12161
AB-1500-1.5,2.5 Outdoor matrix, incandescent wedge-base lamp with lens, 1.5" and 2.5" spacing 1998-1999 ED-11119
AB-1600-1.5,2.5 Outdoor matrix, incandescent wedge-base lamp with lens, 1.5" and 2.5" spacing 1998-1999 ED-11946
ED-10941
ED-11943
ED-11944

Vanguard

Dynamic Message Signs

Vanguard Product Photo

Family of Dynamic Message Signs that informs the public with up to date traveler information.

Model Description Active Production Manuals
Legacy Series Pre-Vanguard Dynamic Message Signs 1988-1998 Custom Manual
VF-1000 Series Dynamic Message Signs 1998-2001 Custom Manual
VF-1100 Series Dynamic Message Signs 2002-2005 Custom Manual
VF-1300 Series Dynamic Message Signs 2001-2005 Custom Manual
VF-1400 Series Dynamic Message Signs 2002-2005 Custom Manual
VF-2000 Series Dynamic Message Signs GEN II 2005-2010 Custom Manual
VF-2000 Series Dynamic Message Signs Amber (20mm, 34mm, 46mm) 2005-2010 Custom Manual

Venus

Message and animation display control systems.

Venus 1500 Logo

Family of message and animation display control systems. Used for complete content creation and scheduling software.

Model Description Active Production Manuals
Venus/Olympian 80 Software that controls 1 line displays at a max. size of 7x128 lamp matrix. Capacity of 32 messages. 1981-1994 ED-0948
Venus 1000 Software that creates and sends messages to the controller, that is built into the display cabinet, via modem or direct wire. Controller can store 32 messages with 32 frames in each. 1992-1999 ED-7471
Venus 1500 Version 1.x Software that creates and sends messages to Galaxy, SunSpot, InfoNet and DataTrac displays. From October 1995 to May 2001. 1995-2007 ED-9067
Venus 1500 Version 2.x Software that creates and sends messages to Galaxy, SunSpot, InfoNet and DataTrac displays. From May 2001 to August 2002. 2001-2007 ED-12717
Venus 1500 Version 3.x Software that creates and sends messages to Galaxy, SunSpot, InfoNet and DataTrac displays. From August 2002 to May 2008. 2001-2010 ED-13530
Venus 2000 Replacement software for Venus/Olympian 80 with graphic capability and mouse compatibility that controlled 1-2 line displays at a max. size of 16x128 lamp matrix via modem. 1980-1997 N/A
Venus 4000 (1980-87) Message/animation display controller, including hardware, on multiple line indoor and outdoor displays with a max. size of 32x96 via modem or direct wire. 1980-1987 N/A
Venus 4100/4200/4300/4400 Display control system, including hardware, designed for single or multi-line applications with unlimited offline storage. 1980-1994 N/A
Venus 4600 The Venus 4600 is an electronic animated display system and message center. This system interfaces with many other sports stats programs and provides real-time data for sporting events. 1990-1998 ED-4062
Venus 5000 (1985-1988) Display control system for multi-line displays up to 32,000 lamps in size with a max. height of 128 and max. length of 512. 1985-1988 N/A
