AF-6700 Series Outdoor Galaxy® Message Displays

The AF-6700 series provides rail passengers with up-to-the-minute schedules, destination information and advertising viewed from the rail platform. It guides patrons with 6mm or 8mm pixel spacing for clear text which is legible from a wide range of viewing distances. Due to its robust design and NEMA 4X industrial-strength cabinet, the vandal-resistant AF-6700 can be installed and easily maintained in outdoor locations such as rail platforms, whether above ground or subway. The AF-6700 features wired, fiber optic and wireless communication options – making the display an ideal solution for rail applications.


6 mm Full-Color LED Signs

With the tightest pixel pitch available for mass transit displays, the AF-6700 series 6 mm full-color LED display is sure to catch passengers' eyes with clear and vibrant imaging combined with text.


Technical Specifications

Pixel pitch: 6 mm (0.24") center-to-center

Color capability: Full-Color (RGB)

LEDs per pixel: 3-in-1 RGB

View Product Specifications

Oxford Circus

Did you know the brain interprets messages in color 35% faster?

Your agency can improve customer satisfaction through the use of full-color high resolution LED signage by addressing human sensory abilities of color recognition and emotion.

See the Benefits of Full-color for Mass Transit


6 mm Monochrome LED Signs

Norrkoping Sweden 6 mm Monochrome

Clear, instantly-recognizable messages from one of the most reliable and rugged digital displays to hit the railway market, the AF-6700 series 6 mm monochrome LED display withstands the test of time and weather with a durable cabinet built to endure outdoor elements and resist brake dust.


Technical Specifications

Pixel pitch: 6 mm (0.24") center-to-center

Color capability: Monochrome (amber)

LEDs per pixel: 1 amber

View Product Specifications


8 mm Monochrome LED Signs

The AF-6700 series 8 mm monochrome LED display is a classic choice for railway platform use. Choose whether to display messages in highly visible text on a single-face display, or both sides with a double-face display.


Technical Specifications

Pixel pitch: 8 mm (0.3") center-to-center

Color capability: Monochrome (amber)

LEDs per pixel: 1 amber

View Product Specifications

DRIS SAN Netherlands 8 mm Monochrome

Features and Benefits

  • Supports a wide range of character sizes and will meet ADA requirements
  • NEMA 4X rating allows the cabinet to withstand extreme weather conditions, brake dust and corrosive environments
  • Application of conformal coating to all electronic components provides protection from harsh environmental conditions
  • DVS software protocol easily integrates with existing third-party software used by most system integrators
  • RS422 or Ethernet (wired or fiber) communication options allow for flexible installation
  • A pixel test allows central control the ability to monitor LED status
  • In the event of communication loss to the display, the sign has the ability to be configured to blank
  • AF-6700 series displays are available in single-face (SF) or double-face (DF) configurations

Series Technical Specifications

Estimated LED Lifetime: 100,000+ hours
LED Viewing Angle: 120°
Contrast Enhancement: Contrast enhancing polycarbonate face
Service Access: Front access
Graphic Capability: Text, graphics, logos, multiple font styles and sizes
Control Software: DVS software or third-party integrators using DVS SDK (software developers kit)
Power: 120 or 240 VAC single phase
Display Dimming: 99 levels (automatic or manual control)
Communication Options: RS422 and Ethernet (wired or fiber)
Compliance: UL listed, NEMA 4X cabinet, NEC

Want to learn more? We're here to help.

Let our experts answer questions about the benefits of products customized for you.
